Azuryt 2 – tilt table – 14.501.009

Description

[et_pb_section bb_built=”1″][et_pb_row][et_pb_column type=”4_4″][et_pb_text]

This rehabilitation table is designed for use in orthopedic, neurologic, rheumatic diseases treatment as well as in rehabilitation. Places of use are: hospitals, clinics, health centers and rehabilitation centers.

TECHNICAL DATA

Power supply:  230 V
Power of actuator:  6000 N
Power of actuator II (tilting process): 8000 N
As a rule the upholstery consists of two elements: footrest and main plate
Dimensions of the table (L x P x H): 200 x 68 x 58-96 cm
Weight of the table (without patient): 105 Kg
Angle adjustment:
– of the main plate +87°
– table height adjustment range 58 – 96 cm
Maximum patient weight: 130 Kg.

ATTENTION: Avoid surcharge of the table plate. Maximum surcharge (in elevation and lowering) is 130 Kg, static surgarge is no more than 150 kg evenly distributed on the whole surface of the table.

STANDARD EQUIPMENT

• No 3 – Belts for stabilization – 13.022.092
• No 1 – Fixing rods for stabilization belts (head, trunk, head) – 14.501.017

OPTIONAL EQUIPMENT

• Table with adjustable height – 14.501.019
• Rechargeable battery
• Central wheel system for mobility – 14.501.016

COLOURS
